REST vs GraphQL

What are the similarities between GraphQL and REST?

Both GraphQL and REST are popular API architecture styles that enable the exchange of data between different services or applications in a client-server model.

APIs facilitate the access of data and data operations like this:

  1. A client sends an API request to an endpoint or multiple endpoints on a server

  2. The server gives a response that contains data, data status, or error codes

REST and GraphQL allow you to create, modify, update, and delete data on a separate application, service, or module via API. APIs developed with REST are known as RESTful APIs or REST APIs. Those developed with GraphQL are simply GraphQL APIs.

Frontend and backend teams use these API architectures to create modular and accessible applications. Using an API architecture helps keep systems secure, modular, and scalable. It also makes systems more performant and easier to integrate with other systems.

Next, we discuss some other similarities between GraphQL and REST.

Architecture

Both REST and GraphQL implement several common API architectural principles. For example, here are principles they share:

  • Both are stateless, so the server does not save response history between requests

  • Both use a client-server model, so requests from a single client result in replies from a single server

  • Both are HTTP-based, as HTTP is the underlying communication protocol

Resource-based design

REST and GraphQL both design their data interchange around resources. A resource refers to any data or object that the client can access and manipulate through the API. Each resource has its own unique identifier (URI) and a set of operations (HTTP methods) that the client can perform on it.

For example, consider a social media API where users create and manage posts. In a resource-based API, a post would be a resource. It has its own unique identifier, for example, /posts/1234. And it has a set of operations, such as GET to retrieve the post in REST or query to retrieve the post in GraphQL.

Data exchange

Both REST and GraphQL support similar data formats.

JSON is the most popular data exchange format that all languages, platforms, and systems understand. The server returns JSON data to the client. Other data formats are available but less commonly used, including XML and HTML.

Similarly, REST and GraphQL both support caching. So, clients and servers can cache frequently accessed data to increase speed of communication.

Language and database neutrality

Both GraphQL and REST APIs work with any database structure and any programming language, both client-side and server-side. This makes them highly interoperable with any application.

What REST limitations does GraphQL attempt to overcome?

GraphQL emerged in 2012 as a response to the need for speed in emerging social media platforms. Developers found that existing API architectures, like REST, were too lengthy and structured to produce news feeds efficiently.

Next, we discuss some of the challenges they faced.

Fixed-structure data exchange

The REST API requires client requests to follow a fixed structure to receive a resource. This rigid structure is easy to use, but it’s not always the most efficient means to exchange exactly the data needed.

Overfetching and underfetching

REST APIs always return a whole dataset. For example, from a person object in the REST API, you would receive the person’s name, date of birth, address, and phone number. You would get all of this data even if you only needed a phone number.

Similarly, if you wanted to know a person’s phone number and last purchase, you would need multiple REST API requests. The URL /person would return the phone number and the URL /purchase would return purchase history.

Social media developers had to write a lot of code just to process API requests, which affected performance and user experience.

GraphQL emerged as a query-based solution. Queries can return the exact data in only one API request and response exchange.

Key differences: GraphQL vs. REST

A REST API is an architectural concept for application communication. On the other hand, GraphQL is a specification, an API query language, and a set of tools. GraphQL operates over a single endpoint using HTTP.

In addition, REST development has been more focused on making new APIs. Meanwhile, GraphQL’s focus has been on API performance and flexibility.

Next, we give some more differences.

Client-side request

Here’s what a REST request uses to work:

  • HTTP verbs that determine the action

  • A URL that identifies the resource on which to action the HTTP verb

  • Parameters and values to parse, if you want to create or modify an object within an existing server-side resource

For example, you use GET to get read-only data from a resource, POST to add a new resource entry, or PUT to update a resource.

In contrast, here’s what GraphQL requests use:

  • Query for getting read-only data

  • Mutation for modifying data

  • Subscription to receive event-based or streaming data updates

A data format describes how you would like the server to return the data, including objects and fields that match the server-side schema. You can also input new data. Internally, GraphQL sends every client request as a POST HTTP request.

Data returned to the client

Under REST architecture, data is returned to the client from the server in the whole-of-resource structure specified by the server. The following examples show returned data in REST and GraphQL.

Example of returned data in REST

In REST, GET /posts returns the following:

[
  {
    "id": 1,
    "title": "First Post",
    "content": "This is the content of the first post."
  },
  {
    "id": 2,
    "title": "Second Post",
    "content": "This is the content of the second post."
  },
  {
    "id": 3,
    "title": "Third Post",
    "content": "This is the content of the third post."
  }
]

Example of returned data in GraphQL

When you use GraphQL, only the data specified in the structure given by the client is returned.

GET /graphql?query{post(id: 1) {id title content}} returns only the first post:

{
  "data": {
    "posts": [
      {
        "id": "1",
        "title": "First Post",
        "content": "This is the content of the first post."
      },
]}}

Server-side schema

GraphQL uses a server-side schema to define data and data services, which differs from a REST API.

The schema, written in GraphQL schema definition language, includes details like these:

  • Object types and fields that belong to each object

  • Server-side resolver functions that define an operation for each field

The schema explicitly defines types to describe all data available on the system and how clients can access or modify that data.

On the other hand, REST APIs do not require a server-side schema. But you can define it optionally for efficient API design, documentation, and client development.

Versioning

As APIs evolve, their data structures and operations may change. For clients without the knowledge of these changes, it can break their systems or introduce unknown errors.

REST APIs often include versioning in the URL to solve this issue, like https://example.com/api/v1/person/12341. However, versioning is not mandatory, and it can lead to errors.

GraphQL requires API backward compatibility. So deleted fields return an error message, or those with a deprecated tag return a warning.

Error handling

GraphQL is a strongly typed API architecture, which means that it requires a detailed description of the data, its structure, and data operations in the schema. Due to the level of detail in the schema, the system can automatically identify request errors and provide useful error messages.

REST APIs are weakly typed, and you must build error handling into the surrounding code. For example, if a PUT request parses a number value as text instead of as an integer, the system does not identify the error automatically.

When to use GraphQL vs. REST

You can use GraphQL and REST APIs interchangeably. However, there are some use cases where one or the other is a better fit.

For example, GraphQL is likely a better choice if you have these considerations:

  • You have limited bandwidth, and you want to minimize the number of requests and responses

  • You have multiple data sources, and you want to combine them at one endpoint

  • You have client requests that vary significantly, and you expect very different responses

On the other hand, REST is is likely a better choice if you have these considerations:

  • You have smaller applications with less complex data

  • You have data and operations that all clients use similarly

  • You have no requirements for complex data querying

It’s also possible to build a single application with both GraphQL APIs and REST APIs for different areas of functionality.

How to use both GraphQL and REST over the same API

Upgrading a RESTful API to a GraphQL API is possible without performing a complete rewrite.

Here’s an outline of the process:

  1. Understand the data model of the RESTful API. To do this, examine the shape of the data in each URL resource.

  2. Write the GraphQL schema from the data model.

  3. Determine which operations clients perform on the data and include them into the schema.

  4. Build a resolver function in the server-side code for each field in the schema.

  5. Create a GraphQL server with the resolvers and schema.

After this, clients can communicate with your API using either GraphQL or REST.

Summary of differences: REST vs. GraphQL

REST

GraphQL

What is it?

REST is a set of rules that defines structured data exchange between a client and a server.

GraphQL is a query language, architecture style, and set of tools to create and manipulate APIs.

Best suited for

REST is good for simple data sources where resources are well defined.

GraphQL is good for large, complex, and interrelated data sources.

Data access

REST has multiple endpoints in the form of URLs to define resources.

GraphQL has a single URL endpoint.

Data returned

REST returns data in a fixed structure defined by the server.

GraphQL returns data in a flexible structure defined by the client.

How data is structured and defined

REST data is weakly typed. So the client must decide how to interpret the formatted data when it is returned.

GraphQL data is strongly typed. So the client receives data in predetermined and mutually understood formats.

Error checking

With REST, the client must check if the returned data is valid.

With GraphQL, invalid requests are typically rejected by schema structure. This results in an autogenerated error message.
